Product Overview
The AA-EB-1G-HL is a rugged, surface-mounted electrical security enclosure built to protect critical single-gang power access points in high-risk environments. Featuring a heavy-duty cross bar hitch lock system for superior tamper resistance and 12-gauge stainless steel construction, it provides unmatched protection against vandalism, theft, and abuse. With integrated spray-deflective housing, conduit entry from both the rear and bottom, and a removable backplate that supports recessed or surface installs, it is ideal for schools, parks, transit hubs, military facilities, or anywhere security and durability are essential.
Note 1: Hitch lock is included.
Note 2: Keyed alike available upon request.
Note 3: Receptacle outlet is not included with the housing. Most boxes on the market should fit, but for a known receptacle box that was tested to fit, Click here for 1 Gang - Weatherproof Electrical Outlook Box and Cover.
UL Certification & Code Compliance
Our heavy-duty enclosures are engineered strictly as secondary architectural physical security hardware. The AA-EB-1G-HL does not house electrical wiring; it is designed to be mounted directly to the structural wall over your existing, fully compliant, UL-listed electrical box and its associated UL-listed cover. Because our product operates entirely outside the electrical system, it does not require an independent UL electrical listing. To comply with local Authority Having Jurisdiction (AHJ) bonding requirements (such as NEC 250), the stainless steel enclosure can be readily bonded to the equipment grounding conductor by your installing electrician.
Key Features
- Cross Bar Hitch Lock: Unique locking system increases resistance to prying and tampering while simplifying secure access for maintenance personnel.
- 12-Gauge Vandal Resistant Construction: Heavy-duty 304L or 316L stainless steel resists impact, rust, and abuse.
- Weather Deflection: Shielded design keeps out water spray, debris, and environmental contamination.
- Dual Conduit Access: Accepts ½” and ¾” conduit (up to 0.922" OD) from both the rear and bottom.
- LEED Friendly Build: Made with recyclable materials to meet sustainable building certifications.
- Made in the USA: Precision TIG-welded and built to last with deburred edges and a professional finish.
Material & Warranty Options
Choose from 12-gauge 304L stainless steel or marine-grade 316L stainless steel for saltwater or coastal installations. All units feature a corrosion-resistant Satin #4 brushed finish. When properly installed and locked, this unit is fully backed by our Anti-Vandalism Warranty (protects against prying by hand/body and heavy impact). For complete coverage details, please review our Warranty page.
Specifications & Compatibility
- Exterior Dimensions: 3 ¾” W x 8 ¼” H x 4 ¾” D
- Interior Dimensions: 3 ¼” W x 7 ½” H x 4 ⅜” D
- Rear Opening: 3 ¼” W x 5” H
- Weight: 6.5 lbs
- Compatibility: Fits most standard single-gang duplex receptacle boxes (not included), including the Greenfield B23BRS Box and Greenfield CDRVPS Weatherproof Cover.
- Models: AA-EB-1G-HL-304L-12g, AA-EB-1G-HL-316L-12g
Installation Guidance
Secure fixture to the wall with appropriate 3⁄8” stainless steel anchoring hardware (not provided) for optimal installation strength. Recommend 3⁄4” or greater back bracing for walls. Partitions may require T-nuts or other suitable anchoring devices. When possible, it is recommended that units be through-bolted back to back providing optimal installation strength. The removable backplate supports both surface or recessed mounting.
Specification Guide
Security Box shall be constructed with 12 gauge 304L or 12 gauge 316L Stainless Steel joined /w TIG welds and edges de-burred. Security Box shall not be cross-metal contaminated during manufacturing construction. Security Box shall provide protective cover against drip and spray. Security Box shall be secured with Bar Style Hitch Lock. Security Box shall have 3⁄8” mounting holes. Security Box shall accommodate standard electrical outlet styles. 12 Gauge models shall include an Anti-Vandalism Warranty when properly installed and locked while in service. 316L SS shall be used for US Navy maritime use or if exposure to salt water is prevalent.
Product Demonstration
Note! This video is a demonstration of a similar model within our electrical enclosure line. It is provided to give you an idea of the heavy-duty features, material thickness, and construction techniques utilized in this product line.
- Material Quality [00:00:22]: A magnet test demonstrating the use of high-quality, non-magnetic stainless steel.
- Extreme Durability [00:02:39]: Stick around to the end of the video for a demonstration of a baseball bat impact test on our 12-gauge stainless steel material!
